Code Height Width Depth Weight Other
Refs
Narrative
CG2 300mm 300mm 150mm 32kg BCB 300 Electric Cables
CG2B 300mm 300mm 150mm 32kg High Voltage Cables
CG2C 300mm 300mm 150mm 32kg Fibre Optic Cables
CG2D 300mm 300mm 150mm 32kg Gas
CG2E 300mm 300mm 150mm 32kg Water
CG2F 300mm 300mm 150mm 32kg DHM
CG2G 300mm 300mm 150mm 32kg Boundary
CG2H 300mm 300mm 150mm 32kg BT
CG2J 300mm 300mm 150mm 32kg SP
CG2A1 300mm 300mm 225mm 48kg D
CG2A2 300mm 300mm 225mm 48kg DD
CG2A3 300mm 300mm 225mm 48kg J
CG3 600mm 600mm 100mm 89kg Electric Cables
CG4 300mm 300mm 75mm 16kg Fire Mains
CG5 150mm 300mm 150mm 15kg Highway Boundary
CG5A 100mm 100mm 500mm 12kg HB
CG5B 150mm 300mm 105mm 11kg Highway Boundary
CG6 250mm 450mm 105mm 26kg Filter Drain Below
CG8 150mm 900mm 60mm 18kg Flood Protection Do not remove

Indicator post

Marker post with anchor

Hydrant post

Code Height Width Depth Weight Other
Refs
Narrative
CG1 770mm 160mm 75mm 24kg Type 2,
BCP1
Electric Cables
CG1A 770mm 160mm 75mm 24kg Type2
BCP2
Fibre Optic Cables

Bespoke Units

Want something different? We can offer bespoke units with cast-in branding, unique site references, or logos in custom sizes and shapes for project-specific needs. Speak to our team on 01952 588885 for more information

Common Applications

  • Solar Farms
  • Mark buried cable routes and inverter locations
  • Demarcate boundaries or zoning areas
  • Wind Energy Sites
  • Identify turbine cabling, ducting, and fibre runs
  • Use for wayfinding or site access markers
  • Battery Storage Facilities (BESS)
  • Highlight buried HV and LV connections
  • Indicate fire break zones or containment areas
  • Substations & Grid Infrastructure
  • o Mark out earthing loops, cable corridors, and services
  • o Clearly define ownership and safety zones

Why Choose Elite Precast Marker Solutions?

  • Trusted by utilities, contractors, and developers nationwide.
  • Fast lead times with large-scale UK production capacity.
  • Expert team on hand to support specification and design.
  • Proven performance in energy, rail, telecoms, and infrastructure sectors.

Mark It Once — Mark It Right

Our marker blocks and posts provide a cost-effective, permanent solution to identifying key services and infrastructure on renewable energy sites. With unmatched strength and clarity, our products ensure your critical systems are protected — above and below ground
Need help specifying the right marker solution for your project?

Contact our team today on 01952 588885 for a quote or bespoke options tailored to your site.
